UNARMOURED CABLES
BCG Compression Cable Gland
Cable retention and sealing at the entry for unarmoured cable applications.
Compression + retention
Brass / stainless steel. Confirm material, finish and final specification with your enquiry.
FUNCTION & APPLICATION
What makes BCG different?
BCG is a compression gland family. Confirm the exact entry thread and the permissible cable range for the supplied size before selecting it for your enclosure.
How to choose
Use actual cable dimensions, not the conductor cross-section printed on the cable. The nominal inch size below is a catalogue designation, not a confirmed thread standard or cable-diameter range.
Before you order
Send the cable data sheet, entry thread, material, finish and quantities. Ask for current product-specific performance and installation documents.
Product family names do not establish an IP rating, hazardous-area approval or certification. Confirm any required rating for the supplied design.
REFERENCE DRAWING
Read the design. Check the dimensions.
Drawing labels refer to the catalogue geometry. Use the confirmed data sheet to check thread engagement, dimensions and installation clearances.
COMPLETE CATALOGUE TABLE
Every listed size. Every dimension.
15 catalogue rows · Source page 9 · Dimensions in mm unless stated otherwise.
Scroll the table horizontally to see every column. † marks a source entry requiring confirmation.
| Size (in) | Cable notation (source) | B | A | C | F | D (1) | D (2) | Catalogue code |
|---|---|---|---|---|---|---|---|---|
| 1 | 4×10 | 0 † | 0 † | 0 † | 0 † | 0 † | 0 † | MEG-BCG 1 |
| 1 | 4×16 | 0 † | 0 † | 0 † | 0 † | 0 † | 0 † | MEG-BCG 1 |
| 1¼ | 3×25+10 | 25 | 31 | 11 | 25 | 36.5 | 40 | MEG-BCG 1¼ |
| 1¼ | 3×25+16 | 25 | 31 | 11 | 25 | 36.5 | 40 | MEG-BCG 1¼ |
| 1½ | 3×50+25 | 31 | 37 | 11 | 27 | 42.5 | 46.5 | MEG-BCG 1½ |
| 1½ | 3×70+35 | 31 | 37 | 11 | 27 | 42.5 | 46.5 | MEG-BCG 1½ |
| 2 | 3×95+50 | 41 | 48 | 14 | 32 | 55 | 61 | MEG-BCG 2 |
| 2 | 3×120+70 | 41 | 48 | 14 | 32 | 55 | 61 | MEG-BCG 2 |
| 2¼ | 3×150+70 | 52 | 63 | 15.5 | 30 | 68 | 75 | MEG-BCG 2¼ |
| 2¼ | 3×185+95 | 52 | 63 | 15.5 | 30 | 68 | 75 | MEG-BCG 2¼ |
| 2½ | 3×240+120 | 62 | 70 | 17 | 35 | 76 | 85 | MEG-BCG 2½ |
| 3 | 3×300+150 | 73 | 82 | 17.5 | 37 | 91 | 100 | MEG-BCG 3 |
| 4 | 3×300 Armed † | 90 | 105 | 20 | 58 | 112 | 123 | MEG-BCG 4 |
| 5 | 0 † | 105 | 112 | 25 | 62 | 138 | 148.5 | MEG-BCG 5 |
| 6 | 0 † | 124 | 145 | 25 | 65 | 165 | 175 | MEG-BCG 6 |
† Zero values are reproduced from the catalogue, not confirmed dimensions. The 4-inch row says “Armed” although this family is described as unarmoured: confirm suitability. D spans two unlabelled subcolumns, retained as D (1) and D (2). Cable notations are not clamping ranges or automatic selection rules; the inch size does not establish a thread standard.
COMPLETE THE INSTALLATION
Choose the matching accessories.
Explore lock nuts, earth tags, reducers, nipples and stopping plugs. Confirm the matching thread, material and installation needs.
LET’S GET THE DETAILS RIGHT
Tell us what your project needs.
Send your product code, cable details and quantities. If you are still comparing options, our team can help you clarify the selection.
